Specifications
Standard : EN818-2
Safety ratio: 4 times
Application range: lifting
Marerial: High quality alloy containing Cr,Ni,Mo
Surface treatment:oiled,blackening,hot dip galvanized ,electrogalvanized,carburization,polishing
Note : The rated load capacity will reduce to 20% when the hook go through the chain when it comes to two leg chain sling
Dia | Rated load | Parameters of the main link ring | Weight/M | Weight of incresing 1 M |
(mm) | (kg) | (mm) | (kg) | （kg） |
6 | 2400 | 80×144×22 | 2.12 | 1.58 |
8 | 4000 | 100×180×26 | 3.58 | 2.76 |
10 | 6300 | 120×216×32 | 6.4 | 4.4 |
12 | 8820 | 120×216×35 | 8.2 | 6.2 |
14 | 12600 | 120×216×35 | 13.7 | 8 |
18 | 20160 | 160×288×42 | 18 | 13.6 |
22 | 30200 | 200×360×55 | 30.5 | 19 |
24 | 35300 | 200×360×60 | 36.6 | 23.2 |
26 | 42800 | 220×396×67 | 48.2 | 27.4 |
30 | 55400 | 220×396×72 | 58.5 | 36 |
34 | 73000 | 240×430×82 | 77.7 | 45.4 |
Attention to the Chain sling of welded construction
1 The overloading is not allowed .
2 Knoting or twisting are all forbbiden；
3 Must use chain adjuster to adjust the length of chain sling
4 loading using the top of lifting hook is not allowed .
5 Working temperature: -40℃~+200℃
6 The lifting capacity will decrease by 90% when it over +200℃
7 The lifting capacity will decrease by 75% when it over +300℃
8 Pls don’t use on the temperature which over 400℃
Certificate
We have achieved many awards both domestic and worldwide.Pls see our achievements on the chain sling as bellow :
