Specifications
Standard : GB/T20652-2006
Safety ratio: 4 times
Application range: lifting
Marerial: High quality alloy containing Cr,Ni,Mo
Surface treatment:oiled,blackening,hot dip galvanized ,electrogalvanized,carburization,polishing
Note : The rated load capacity will reduce to 20% when the hook go through the chain
Model | Diameter (d)mm | WLL(T) | Master link | Weight(Kg/M) | |
α≤45˙ | 45<α≤60˙ | A*B*D | |||
DL8(2)-6 | 6 | 1.568 | 1.12 | 60*110*13 | 0.79 |
DL8(2)-8 | 8 | 2.8 | 2 | 75*135*18 | 1.38 |
DL8(2)-10 | 10 | 4.41 | 3.15 | 90*160*22 | 2.2 |
DL8(2)-13 | 13 | 7.42 | 5.3 | 100*180*26 | 3.8 |
DL8(2)-16 | 16 | 10.92 | 7.8 | 110*200*32 | 5.63 |
DL8(2)-20 | 20 | 15.68 | 11.2 | 160*300*40 | 8.6 |
DL8(2)-22 | 22 | 21 | 15 | 180*340*45 | 10.2 |
Attention to the lifting chain sling
Avoilding destroying the lifting items ,meanwhile be careful on the lifting chain sling itself .To avoild the fall out and rotate should we follow the bellow conditions :
a)Single leg lifting chain sling –the lifting point should be vertically above the center of gravity of the lifting object.
b) Two leg lifting chain sling – the lifting point shall be located on botnh sides of the lifting object and the lifting point shall be above the center of gravity .
Certificate
We have achieved many awards both domestic and worldwide.Pls see our achievements on the chain sling as bellow :
