Specifications
Endless wire rope sling is through the world's most advanced special winding equipment, after a special process woven into the ring rope
Suitable for transformer, shipbuilding and special machinery and a variety of environment in large lifting special requirements.The minimum breaking force of wire rope without joint is 6 times of the working load.
The characters of endless wire rope sling
Its characteristic is the rope body which is soft, there are lots of lifting points , can solve the questions of small limited space and high loading capacity .
Art.No. | Dia | （N.W.Kg，m) | Breaking | single WLL | Double | Art.No. | Dia | （N.W.Kg，m) | Breaking | single WLL | Double |
Diameter | Load | KN | KN | Diameter | load | KN | KN | ||||
(mm) | (kg) | 0° | 45°/90° | (mm) | (kg) | 0° | 45°/90° | ||||
ZS0204010 | 10 | 0.21 | 60 | 10 | 18/14 | ZS0204118 | 118 | 41.58 | 7800 | 1300 | 2410/1830 |
ZS0204012 | 12 | 0.35 | 100 | 16 | 30/20 | ZS0204135 | 135 | 46.9 | 10200 | 1700 | 3100/2400 |
ZS0204016 | 16 | 0.59 | 180 | 30 | 56/40 | ZS0204148 | 148 | 55.79 | 12000 | 2000 | 3700/2800 |
ZS0204019 | 19 | 0.84 | 240 | 40 | 74/56 | ZS0204160 | 160 | 65.52 | 14400 | 2400 | 4400/3400 |
ZS0204023 | 23 | 1.51 | 380 | 63 | 117/88 | ZS0204172 | 172 | 76.3 | 16800 | 2800 | 5200/4000 |
ZS0204029 | 29 | 2.36 | 480 | 80 | 148/113 | ZS0204184 | 184 | 89.6 | 18000 | 3000 | 5500/4200 |
ZS0204034 | 34 | 2.86 | 600 | 100 | 185/141 | ZS0204196 | 196 | 102.2 | 20400 | 3400 | 6300/4800 |
ZS0204040 | 40 | 3.99 | 900 | 150 | 278/212 | ZS0204208 | 208 | 115.5 | 23800 | 3800 | 7000/5370 |
ZS0204046 | 46 | 6.02 | 1200 | 200 | 370/282 | ZS0204220 | 220 | 129.5 | 25200 | 4200 | 7700/5940 |
