heavy duty eye to eye lifting web nylon slings belt 10 ton

Availability:
Quantity:

Product description:

The lifting web sling is used for lifting heavy loads it's made of high-strength polyester and consists of 2-4 layers of webbing.

The webbing slings are specially designed for safe lifting,  it is lightweight but extremely tough, and the flexibility can reduce shock while loading.


Product parameters:

Standard: EN1492-1, ISO4878

The products comply with CE and GS safety requirements

Material: High-strength polyester (100%PES)

Safety factor: 4:1, 5:1, 6:1, 7:1

Length: Can be customized

Working load: 10T

Color: orange

Elongation: ultimate working elongation <2% Breaking elongation <12%

Temperature range: - 40°C - 100 °C

Layer: 2-4 (special specifications can be customized)


1


Eye and eye webbing sling

Art. No.

WLL

Width (mm)

Min Length

Max Length

Eye Length

(kg)

5:1/6:1

7:1

(m)

(m)

(mm)

ZS0102K-1

1000

25

30

0.8

100

300

ZS0102K-2

2000

50

60

1

100

300

ZS0102K-3

3000

75

90

1

100

350

ZS0102K-4

4000

100

120

1.5

100

500

ZS0102K-5

5000

125

150

1.5

100

550

ZS0102K-6

6000

150

180

1.5

100

600

ZS0102K-8

8000

200

240

2

100

700

ZS0102K-10

10000

250

300

2

100

800

ZS0102K-12

12000

300

300

2

100

900

Heavy eye type webbing sling

Art. No.

WLL

Width (mm)

Min Length

Max Length

Eye Length

(kg)

5:1/6:1

7:1

(m)

(m)

(mm)

ZS0102K0-2

2000

25

30

1.5

100

350

ZS0102K0-4

4000

50

60

1.5

100

400

ZS0102K0-6

6000

75

90

1.5

100

450

ZS0102K0-8

8000

100

120

2

100

500

ZS0102K0-10

10000

125

150

2

100

550

ZS0102K0-12

12000

150

180

3

100

600

ZS0102K0-16

16000

200

240

3

100

700

ZS0102K0-20

20000

250

300

3

100

800

ZS0102K0-24

24000

300

300

3

100

900


Features:

1. Each webbing sling attaches an ID label, which bears all relevant information (including sling length, lifting capacity, date of manufacture, etc.)

2. Different color codes are used to indicate the limits of lifting webbing slings.

3. The webbing slings can be applied to a variety of lifting conditions

4. The webbing slings will not conduct electricity, so there is no risk of electric shock

6. The webbing slings are light and soft, easy to use in a small space.


Precautions:

1. Please avoid using in an acid or alkali environment

2. When lifting goods with sharp corners, edges, or rough surfaces,  should use the webbing sling protector to avoid cuts.

3. Never use webbing slings with damages or defects.

4. Please check the WLL, length, and working position before using.
