Specifications
Introduction of beam clamp :
Hanger: a frame used to suspend a workpiece and cause an electric current to the workpiece in electroplating and related operations.
Feasures:
1. Conform to ANSI/ASME safety standard.
2. Can be easy with threaded handle.
3. Clamp jaw is designed to reduce flange stress by distributing from I-beam flange edge.
4. Fit a wide range of flange width and beams.
5. Suspension bar provides lower headroom.
Optional Extra:
1. Can be supplied with shackle.
2. Specially design with faltened,reinforced jaws.
Lifting beam clamp for bridge
Model | Capacity | I-Beam width (mm) | A Max. | B Min. | B Max. | C | D | E | F Max. | F Min. | G |
BC1 | 1 | 75-230 | 240 | 192 | 367 | 94 | 4 | 218 | 155 | 103 | 20 |
BC2 | 2 | 75-230 | 240 | 192 | 367 | 102 | 6 | 218 | 155 | 103 | 20 |
BC3 | 3 | 80-320 | 330 | 243 | 491 | 132 | 8 | 258 | 223 | 157 | 47 |
Certificate
We have achieved many awards both domestic and worldwide.Pls see our achievements on the chain sling as bellow :
