Specifications
Introduction of beam clamp :
Hanger: a frame used to suspend a workpiece and cause an electric current to the workpiece in electroplating and related operations.
Forms of the beam clamp:
There are lots of forms of hanging, there is general purpose that can apply a few kinds of common parts to be lifted, also have the hang tool that is special for large quantities of parts.For the complex geometry of the plating, some should be equipped with an auxiliary anode, auxiliary cathode or shielding plate.
Feasures:
1. Conform to ANSI/ASME safety standard.
2. Can be easy with threaded handle.
3. Clamp jaw is designed to reduce flange stress by distributing from I-beam flange edge.
4. Fit a wide range of flange width and beams.
5. Suspension bar provides lower headroom.
Optional Extra:
1. Can be supplied with shackle.
2. Specially design with faltened,reinforced jaws.
Lifting beam clamp for bridge
Model | Capacity | I-Beam width (mm) | A Max. | B Min. | B Max. | C | D | E | F Max. | F Min. | G |
BC1 | 1 | 75-230 | 240 | 192 | 367 | 94 | 4 | 218 | 155 | 103 | 20 |
BC2 | 2 | 75-230 | 240 | 192 | 367 | 102 | 6 | 218 | 155 | 103 | 20 |
BC3 | 3 | 80-320 | 330 | 243 | 491 | 132 | 8 | 258 | 223 | 157 | 47 |
BC5 | 5 | 80-320 | 330 | 243 | 491 | 142 | 10 | 258 | 223 | 157 | 47 |
BC10 | 10 | 90-320 | 330 | 259 | 501 | 180 | 12 | 293 | 235 | 175 | 56 |
Certificate
Jiangsu Gostern Rigging CO,LTd as one of professional manufacturersthe in the area.Main products are various types of wire rope, steel wire rope, nylon rope sling, special fiber flexible lifting belt series, flat sling series, safety net, safety belt, lifting chain series, sling series of the beam, and metallurgy fixture series and three dynamic tools series.Products are widely used in metallurgy, machinery, railway, petrochemical, port, electric power, automobile, aviation, construction and other fields.
We have achieved many awards both domestic and worldwide.Pls see our achievements on PVC coated PE or PP coated endless wire rope sling as bellow :
To contact us
Thank you for visiting our website, further questions please feel free to contact us. We will do our best to support you all the time.
