| Construction: | |
|---|---|
| Surface: | |
| Quantity: | |
ZS07
Gostern Rigging
ZS0701
Nominal Dia. | Reference Weight | Nominal Tensile Strength (Mpa) | ||
| 1470 | 1570 | 1670 | ||
| Min Breaking Force | ||||
| (mm) | (kg/100m) | (kN) | (kN) | (kN) |
| 8 | 20.4 | 26.3 | 27.1 | 29.9 |
| 9 | 25.8 | 33.3 | 35.6 | 37.9 |
| 10 | 31.8 | 41.2 | 44.0 | 46.8 |
| 11 | 38.5 | 49.8 | 53.2 | 56.6 |
| 12 | 45.8 | 59.3 | 63.3 | 67.3 |
| 13 | 53.7 | 69.6 | 74.3 | 79.0 |
| 14 | 62.3 | 80.7 | 86.2 | 91.6 |
| 16 | 81.4 | 105.0 | 113.0 | 120.0 |
| 18 | 103.0 | 133.0 | 142.0 | 152.0 |
| 20 | 127.0 | 165.0 | 176.0 | 187.0 |
| 22 | 154.0 | 199.0 | 213.0 | 226.0 |
| 24 | 183.0 | 237.0 | 253.0 | 269.0 |
| 26 | 215.0 | 278.0 | 297.0 | 316.0 |
| 28 | 249.0 | 323.0 | 345.0 | 367.0 |
| 30 | 286.0 | 370.0 | 396.0 | 421.0 |
| 32 | 326.0 | 421.0 | 450.0 | 479.0 |
| 34 | 368.0 | 476.0 | 508.0 | 541.0 |
| 36 | 412.0 | 533.0 | 570.0 | 606.0 |
| 38 | 459.0 | 594.0 | 635.0 | 675.0 |
| 40 | 509.0 | 659.0 | 703.0 | 748.0 |
Nominal Dia. | Reference Weight | Nominal Tensile Strength (Mpa) | ||
| 1470 | 1570 | 1670 | ||
| Min Breaking Force | ||||
| (mm) | (kg/100m) | (kN) | (kN) | (kN) |
| 8 | 20.4 | 26.3 | 27.1 | 29.9 |
| 9 | 25.8 | 33.3 | 35.6 | 37.9 |
| 10 | 31.8 | 41.2 | 44.0 | 46.8 |
| 11 | 38.5 | 49.8 | 53.2 | 56.6 |
| 12 | 45.8 | 59.3 | 63.3 | 67.3 |
| 13 | 53.7 | 69.6 | 74.3 | 79.0 |
| 14 | 62.3 | 80.7 | 86.2 | 91.6 |
| 16 | 81.4 | 105.0 | 113.0 | 120.0 |
| 18 | 103.0 | 133.0 | 142.0 | 152.0 |
| 20 | 127.0 | 165.0 | 176.0 | 187.0 |
| 22 | 154.0 | 199.0 | 213.0 | 226.0 |
| 24 | 183.0 | 237.0 | 253.0 | 269.0 |
| 26 | 215.0 | 278.0 | 297.0 | 316.0 |
| 28 | 249.0 | 323.0 | 345.0 | 367.0 |
| 30 | 286.0 | 370.0 | 396.0 | 421.0 |
| 32 | 326.0 | 421.0 | 450.0 | 479.0 |
| 34 | 368.0 | 476.0 | 508.0 | 541.0 |
| 36 | 412.0 | 533.0 | 570.0 | 606.0 |
| 38 | 459.0 | 594.0 | 635.0 | 675.0 |
| 40 | 509.0 | 659.0 | 703.0 | 748.0 |
