| Load Capacity: | |
|---|---|
| Lifting Height: | |
| Quantity: | |
HSH
Gostern Rigging
ZS121010
Description
Hand hoist is widely used in shipbuilding, electric power, transportation, construction, mining, post and telecommunications and other industries of equipment installation, lifting, mechanical parts pulling.
| Model | WLL (T) | Lifting Height 1.5M-6M Customisable | Test Load (Kn) | Hand Pulling Force at Full Load (N) | No. of Chain | Diameter of Load Chain (MM) | N.W. (KG) |
|---|---|---|---|---|---|---|---|
| HSH-0.75 | 0.75 | 1.5 | 9.2 | 134 | 1 | 6 | 7.7 |
| HSH-1.5 | 1.5 | 1.5 | 18.4 | 196 | 1 | 8 | 11.8 |
| HSH-3 | 3 | 1.5 | 36.8 | 324 | 1 | 10 | 21 |
| HSH-6 | 6 | 1.5 | 73.5 | 340 | 2 | 10 | 32 |
| HSH-9 | 9 | 1.5 | 110.3 | 357 | 3 | 10 | 47 |
Advantages
1. The lever hoist is safe, reliable and durable,
2. Good performance, easy maintenance,
3. Small size, light weight, easy to carry,
4. Small hand force, high efficiency,
5. Perfect structure, beautiful appearance and so on.
The hand hoist is to obtain the linear traction force matching the load by manually pulling the handle with the lever principle, and alternately acts on a clamp body of the load in the movement to drive the load.
Description
Hand hoist is widely used in shipbuilding, electric power, transportation, construction, mining, post and telecommunications and other industries of equipment installation, lifting, mechanical parts pulling.
| Model | WLL (T) | Lifting Height 1.5M-6M Customisable | Test Load (Kn) | Hand Pulling Force at Full Load (N) | No. of Chain | Diameter of Load Chain (MM) | N.W. (KG) |
|---|---|---|---|---|---|---|---|
| HSH-0.75 | 0.75 | 1.5 | 9.2 | 134 | 1 | 6 | 7.7 |
| HSH-1.5 | 1.5 | 1.5 | 18.4 | 196 | 1 | 8 | 11.8 |
| HSH-3 | 3 | 1.5 | 36.8 | 324 | 1 | 10 | 21 |
| HSH-6 | 6 | 1.5 | 73.5 | 340 | 2 | 10 | 32 |
| HSH-9 | 9 | 1.5 | 110.3 | 357 | 3 | 10 | 47 |
Advantages
1. The lever hoist is safe, reliable and durable,
2. Good performance, easy maintenance,
3. Small size, light weight, easy to carry,
4. Small hand force, high efficiency,
5. Perfect structure, beautiful appearance and so on.
The hand hoist is to obtain the linear traction force matching the load by manually pulling the handle with the lever principle, and alternately acts on a clamp body of the load in the movement to drive the load.
