304 Stainless Steel Hoist Chain

Standard: EN818-2
Safety factor: 4 times
Application Rang: lifting hoist
Material: AISI304
Grade: 50

Diameter:	6.3mm 7.1mm 8mm 9mm 10mm 11.2mm 12.5mm 13mm 14mm 16mm
Availability:

Quantity:



Inquire Add to Basket

Model:
ZS0801
Brand:
Gostern Rigging
Code:
ZS080112

Product Description

G80链条图纸

Diameter (mm)		Pitch (mm)		Width (mm)		W.L.L (T)	Weight (kg/m)	Test Load (T)	Min BF (T)
d	tolerance	p	tolerance	min a	max b	W.L.L (T)	Weight (kg/m)	Test Load (T)	Min BF (T)
3	±0.2	9	+0.18	3.6	10.2	0.25	0.2	0.5	1.00
4	±0.2	12	+0.25	4.8	13.6	0.44	0.35	0.88	1.76
5	±0.2	15	+0.3	6	17	0.7	0.55	1.4	2.80
6	±0.2	18	+0.4	7.2	20.4	0.8	0.78	1.6	3.20
6.3	±0.2	19	+0.4	7.2	20.4	0.9	0.85	1.8	3.60
7.1	±0.3	21	+0.4	8.4	23.8	1.2	1.1	2.4	4.80
8	±0.3	24	+0.5	9.6	27.2	1.6	1.4	3.2	6.40
9	±0.4	27	+0.5	10.8	30.6	1.8	1.8	3.6	7.20
10	±0.4	30	+0.6	12	34	2	2.2	4	8.00
11.2	±0.4	34	+0.7	13.2	37.4	2.2	2.6	4.4	8.80
12.5	±0.5	38	+0.8	14.4	40.8	3.1	3.4	6.2	12.40
13	±0.5	39	+0.8	15.6	44.2	3.3	3.8	6.6	13.20
14	±0.6	42	+0.8	16.8	47.6	3.8	4.4	7.6	15.20
16	±0.6	48	+0.9	19.2	54.4	5	5.7	10	20.00

Gostern 304 Stainless Steel High Strength Lifting Chain is made of premium 304 stainless steel material with high tensile strength, excellent corrosion resistance and long service life. It is heat treated and strictly tested to meet EN818-2 and GB/T 20946 standards, with stable performance and safe load capacity.

This G80 304 lifting chain features wear resistance, rust proof and durable structure, widely used in marine grade lifting, hoisting, towing, port, construction and chemical industries. Available in 4mm, 6mm and other custom sizes, it is the ideal choice for heavy duty rigging applications.

We support OEM, ODM and customized length services to meet different working demands.
