ZS01
Gostern Rigging
ZS0103
One-leg | Two-leg | Four-leg | ||
0° | 45° angle | 60° angle | 45° angle | 60° angle |
1.0 | 1.4 | 1.0 | 2.1 | 1.5 |
500 | 700 | 500 | 1050 | 750 |
1000 | 1400 | 1000 | 2100 | 1500 |
2000 | 2800 | 2000 | 4200 | 3000 |
3000 | 4200 | 3000 | 6300 | 4500 |
4000 | 5600 | 4000 | 8400 | 6000 |
5000 | 7000 | 5000 | 10500 | 7500 |
6000 | 8400 | 6000 | 12600 | 9000 |
8000 | 11200 | 8000 | 16800 | 12000 |
10000 | 14000 | 10000 | 21000 | 15000 |
12000 | 16800 | 12000 | 25200 | 18000 |
15000 | 21000 | 15000 | 31500 | 22500 |
20000 | 28000 | 20000 | 42000 | 30000 |
25000 | 35000 | 25000 | 52500 | 37500 |
30000 | 42000 | 30000 | 63000 | 45000 |
One-leg | Two-leg | Four-leg | ||
0° | 45° angle | 60° angle | 45° angle | 60° angle |
1.0 | 1.4 | 1.0 | 2.1 | 1.5 |
500 | 700 | 500 | 1050 | 750 |
1000 | 1400 | 1000 | 2100 | 1500 |
2000 | 2800 | 2000 | 4200 | 3000 |
3000 | 4200 | 3000 | 6300 | 4500 |
4000 | 5600 | 4000 | 8400 | 6000 |
5000 | 7000 | 5000 | 10500 | 7500 |
6000 | 8400 | 6000 | 12600 | 9000 |
8000 | 11200 | 8000 | 16800 | 12000 |
10000 | 14000 | 10000 | 21000 | 15000 |
12000 | 16800 | 12000 | 25200 | 18000 |
15000 | 21000 | 15000 | 31500 | 22500 |
20000 | 28000 | 20000 | 42000 | 30000 |
25000 | 35000 | 25000 | 52500 | 37500 |
30000 | 42000 | 30000 | 63000 | 45000 |
1. Please pay attention to the lifting angle and working load limit during the use.
2. Safety factor 4:1, 5:1 or 6:1. Use within the safety factor range.
3. If the round sling is damaged during use, it cannot be used again.
4. Avoid the impact or vibration of the load.
5. Single leg webbing slings the hanging point must be vertically above the center of gravity of the object to be lifted.
6. The llifting points of the double legs round slings should be on both sides of the cargo, and the hooks are above the center of gravity of the object to be lifted.
1. Please pay attention to the lifting angle and working load limit during the use.
2. Safety factor 4:1, 5:1 or 6:1. Use within the safety factor range.
3. If the round sling is damaged during use, it cannot be used again.
4. Avoid the impact or vibration of the load.
5. Single leg webbing slings the hanging point must be vertically above the center of gravity of the object to be lifted.
6. The llifting points of the double legs round slings should be on both sides of the cargo, and the hooks are above the center of gravity of the object to be lifted.
