Two Leg Wire Rope Sling

Standard: GB/T 16762-2020, EN13414-1
Wire rope: 6x37+FC-1670Mpa (can be changed)
Surface: bright, galvanized, lubricated
Component: master link,pressed wire rope, end fittings
Length: customizable
Availability:
Quantity:
Inquire Add to Basket

  • ZS0405

  • Gostern Rigging

  • ZS040502

Two Wire Rope Sling


2腿钢丝绳索具图纸 Nominal Rope
Diameter
(mm)

W.L.L(kg)角度1_副本
α≤90°
1.4		 90°<α≤120°
1.0
8 798 570
9 1022 730
10 1260 900
12 1820 1300
13 2100 1500
14 2380 1700
16 3220 2300
18 4060 2900
20 5040 3600
22 6020 4300
24 7280 5200
26 8540 6100
28 9800 7000
30 11340 8100
32 12880 9200
36 16380 11700
40 20160 14400
44 24500 17500
48 29260 20900
52 34160 24400
56 39480 28200
60 45360 32400
Wire rope: 6x37+FC-1670Mpa, one leg sling direct WLL(kN)=MBL*0.9/5
WLL will be changed according to specification of the wire rope
