ZS0801
Gostern Rigging
ZS080107
AISI 316 Stainless Steel DIN 766 Windlass Anchor Chain
Gostern AISI 316 Stainless Steel DIN 766 Windlass Anchor Chain is manufactured from premium AISI 316 (V4A) stainless steel material with excellent corrosion resistance, high tensile strength and calibrated short link construction. It is precision welded and strictly tested to meet DIN 766 standards, with stable performance and reliable anchoring capacity
This DIN 766 Windlass Chain features short link design for smooth windlass operation, fully calibrated for compatibility with standard anchor gypsies, widely used as 316 Stainless Steel Calibrated Chain in yachting and boating, as Marine Grade Anchor Chain in commercial vessels, and as Short Link Anchor Chain for permanent mooring systems. Available in 8mm Marine Grade Anchor Chain, 6mm, 10mm, 12mm, 14mm, 16mm and other custom sizes, it is the ideal choice for AISI 316 Stainless Steel DIN 766 Windlass Anchor Chain and Grade 40 Stainless Steel Chain applications
| Diameter d(mm) | Inner Length p(mm) | Inner Width a(mm) | Weight (kg/m) |
| 2 | 12 | 3.5 | 0.07 |
| 3 | 16 | 5 | 0.163 |
| 4 | 16 | 5 | 0.32 |
| 5 | 18.5 | 6 | 0.5 |
| 6 | 18.5 | 7.2 | 0.8 |
| 7 | 22 | 8.4 | 1.1 |
| 8 | 24 | 9.6 | 1.4 |
| 9 | 27 | 10.8 | 1.8 |
| 10 | 28 | 12 | 2.3 |
| 11 | 31 | 13.2 | 2.68 |
| 12 | 36 | 14.6 | 3.11 |
| 13 | 36 | 15.6 | 3.8 |
| 16 | 45 | 19.2 | 5.7 |
*About stainless steel chains
(1) 201 stainless steel chain, suitable for use in dry environments, can easily rust when exposed to water.
(2) 304 stainless steel chain, suitable for outdoor or humid environments, strong corrosion resistance and acid resistance.
(3) 316 stainless steel chain with molybdenum added has better corrosion resistance and pitting corrosion resistance, especially suitable for marine or chemically harsh environments.
We support Custom Length Anchor Chain, OEM, ODM and customized diameter services to meet different working demands.
