DIN766 304 Stainless Steel Short Link Chain

Each link of the DIN766 short link chain is proof-tested and calibrated
Diameter:
2mm
3mm
4mm
5mm
6mm
7mm
8mm
9mm
10mm
11mm
12mm
13mm
16mm
Availability:
Quantity:
Inquire Add to Basket

  • ZS0801

  • Gostern Rigging

  • ZS080107

DIN766 Stainless Steel Short Link Chain



链条图纸

Diameter
d(mm)		 Inner Length
p(mm)		 Inner Width
a(mm)		 Weight
(kg/m)
2 12 3.5 0.07
3 16 5 0.163
4 16 5 0.32
5 18.5 6 0.5
6 18.5 7.2 0.8
7 22 8.4 1.1
8 24 9.6 1.4
9 27 10.8 1.8
10 28 12 2.3
11 31 13.2 2.68
12 36 14.6 3.11
13 36 15.6 3.8
16 45 19.2 5.7
